The Liebert FS system design and safety characteristics allow for a relatively simple and quick instal-
lation. The system is designed to be rolled or lifted into place and bolted to the floor using Liebert's
mounting kit, included with the system. The mounting kit in most cases does not require any special
floor preparations (see3.0 - Unloading and Unpacking).
Figure 14 Dimensions, general layout
!
CAUTION
The Liebert FS system must be installed in accordance with the instructions and drawings in
this manual.
!
CAUTION
Never attempt to install or power up any unit suspected of damage during shipment.
!
CAUTION
The Initial System Startup must be performed ONLY under the supervision of a
Liebert-certified service technician to ensure proper system operation. Failure to abide by
instructions provided herein may void your warranty.
Contact your local Liebert sales representative or Liebert at 1-800-LIEBERT to arrange for
system startup.
71-1/8"
(1801mm)
25"
(636mm)
Front
Top
Bottom
32-1/2"
(828mm)
Right Side
Control
Panel
