Operation
64
• Vitals (USER or above): Key system efficiency and performance measurements are displayed in
Max/Min measurements along with the date recorded.
Figure 74 Vitals history view
• Counters (USER or above) provide totals of run time hours; system and components, and numbers
of startup and shutdown events; contactor closures and bootup. OPERATING HOURS is the total
operating hours in the CHARGE/ DISCHARGE/ READY mode.
Figure 75 Counters
Figure 76 Counters - screen 2
6.4.9 Options
Each option, if installed, can be enabled by pressing its number and its status will then be displayed.
Additional information on setup and operation of these options is available in the related section of
this manual.
Figure 77 Options view
HOME DONE
MAX DRAG POWER:
MIN DRAG POWER:
LAST 10K DRAG:
MAX MISER:
MAX RUNOUT:
1.23 @
1.23 @
10.0 W, 11/30/05
2.0 W, 11/29/05
1.0 W, 11/30/05
12345, 11/28/05
34567, 11/27/05
>>
>>
>>
>>
>>
HOME DONE
>>
>>
>>
>>
>> CONTACTOR CLOSURE:
SHUTDOWN TO OFF:
BOOTUP COUNT:
HOURS SINCE BOOTUP:
OPERATING HOURS: 3
4
5
12.34
1234567
hr
hr
NEXT
HOME
>>
>>
>> PUMP ON-TIME:
FAN#1 ON-TIME:
FAN#2 ON-TIME: 12.34 hr
56.78 hr
19.24 hr
BACK
HOME DONE
1. DCM : INOPERATIVE
2. VIB : OPERATIVE
