7. Interface
Specification
XP100U-H2/ XP100U-H4
XP83U-H6/XP90U-H6/XP100U-H6
Display TFT‐LCD with Touch Screen
Digital/Analog I/O Ports
1 Digital input
1 Digital output
1 S0 input
1 S0 output
4 Analog inputs
Data communication 2 RS485/1 CAN/1 Ethernet
Memory SD-Card up to 8GB
8. Enclosure
Specification XP100U-H2 XP100U-H4
XP83U-H6/
XP90U-H6/
XP100U-H6
Height Width
Depth(mm)
73 x 68 x 36in.
(1840 x 1724 x 930mm: H, W, D)
Weight(kg) 3086lbs (1400kg) 3086lbs (1400kg) 2425lbs (1100kg)
Protection Class NEMA 3R
9. Overvoltage, under voltage and Frequency ranges
Voltage Range
(% of Nominal)
System Condition XP100U-H2 XP100U-H4
XP83U-H6/
XP90U-H6/
XP100U-H6
Trip Time
Vac<50% Grid Minimum Voltage Vac<104 Vac<240 Vac<300 10 cycles
50%≤Vac<88% Grid Under Voltage 104≤Vac<184 240≤Vac<423 300≤Vac<528 2 seconds
88% Normal Operation 184 422 528 -
110% Grid Over Voltage 228 528 660 1 second
120%≤Vac Grid Maximum Voltage 249≤Vac 576≤Vac 720≤Vac 10 cycles
