Page 31
XP100U-H2
Number of GRID cables Cable Size Torque
A, B, C, N 4 300kcmil
All 194℉(90℃) copper wire, 40 lb-ft
tightening torque
PE 1 4AWG
194℉(90℃) copper wire, 40 lb-℉t
tightening torque
PV Connection
PV Array is connected to the inverter through the DC input bus bars which are located on the bottom right of
the field wiring area of the inverter.
CAUTION!
Risk of damage!
Make sure NOT to reverse polarity of the DC input.
DANGER!
Ensure protection against hazardous live voltages during the assembly of the PV installation.
Both positive and negative leads must be correctly isolated.
CAUTION!
