13.
FAULTS & WARNINGS
When a problem occurs in the system, the Inverter will beep and inform the user on the GUI. The Inverter
displays two basic error messages. The first, the fault, is a serious problem that causes the inverter to stop
running. The second, a warning, is a minor problem that does not cease the system operation. The GUI will
indicate faults in red and warnings in yellow. The user can find a description of the different fault and
warnings in the following tables.
WARNING AND FAULT TABLES
Warning
Message
Code
Description
SP1(PV SP) Failure
W01
Failure of the PV side surge protector(SP1)
Reserved
W02
Reserved
PV Fuse Failure
W03
PV side Fuse failure(option)
Ground Fault Warning
W04
The insulation resistance of the PV falls short of the limit set in the
ground fault monitoring for Alert1(option)
Reserved
W05~W19
Reserved
PEBB Over Temp.
Warning
W20
The temperature of the PEBB(Power Electronics Building Block)
heatsink exceeds 75℃(167℉)
PEBB Fan Failure
W21
Failure of a PEBB(Power Electronics Building Block) fan
Reserved
W22~W29
Reserved
SP2(Grid SP) Failure
W30
Failure of the grid side surge protector(SP2)
Reserved
W31~W39
Reserved
Test Mode
W40
The system is working in test mode
