Configuration and Operation
Page 34 Operating Manual KACO blueplanet 5.0TL3 - 9.0TL3
Coun-
try-spec.
setting
menu
level
Display/
setting
Action in this menu/meaning
0 1 2 3 1 Yield counter
Displays the yield in kWh.
 Reset the counter using the “Reset” key.
0 1 2 3 1 Yield today Displays the cumulative yield for the current day.
0 1 2 3 1 Total yield Displays the total yield up to now.
0 1 2 3 1 CO2 savings Displays the calculated CO
2
savings (in kg).
0 1 2 3 1 Oper. hrs cntr
Displays the duration of operation in hours.
 Reset the counter using the “Reset” key.
0 1 2 3 1 Oper. time today Displays the duration of operation on the current day.
0 1 2 3 1 Total oper. time Displays the total operating time.
0 1 2 3 1 Log data display
 Open the menu: Press the right arrow button or the
OK button.
 Measurement data can be transferred to a USB stick
by selecting it and moving it.
0 1 2 3 2 Day display
Displays the recorded operating data graphically.
1. Select the measured value to be displayed.
Supported measured values:
• Grid power P(grid)
• DC power per string P(PV) 1-2
• DC voltage per string U(PV) 1-2
• Unit temperature
2. Select a day.
3. Press the OK button.
» The display shows the selected data.
 Press any button to return to the previous menu.
0 1 2 3 2 Month display
Displays the recorded operating data graphically.
1. Select a month.
2. Press the OK button.
» The display shows the selected data.
 Press any button to return to the previous menu.
0 1 2 3 2 Year display
Displays the recorded operating data graphically.
1. Select a year.
2. Press the OK button.
» The display shows the selected data.
 Press any button to return to the previous menu.
0 1 2 3 2 CSV log data
 Open the menu: Press the right arrow button or the
OK button.
0 1 2 3 3 Decimal separator
 Select decimal sign for export of saved operating
data.
