Technical Data
Page 10 Operating Manual KACO blueplanet 5.0TL3 - 9.0TL3
4 Technical Data
4.1 Electrical Data
Product name: KACO blueplanet 5.0 TL3 6.5 TL3 7.5 TL3 9.0 TL3
Input levels
MPP@Pnom range from [V] to [V] 240 ... 800 310 ... 800 350 ... 800 420 ... 800
Operating range from [V] to [V] 200 ... 950
Starting voltage [V]* 250
No-load voltage (U
OC max
) [V] 1 000 (start to 950)
Max. input current [A] 2 x 11
Max. power per tracker [W]
5 200 6 700 7 700 8 800
Number of strings 2
Number of MPP controls 2
max. short-circuit current (I
SC max
) [A] 16 (per tracker) / 32 (for parallel switching)
Overvoltage safety class III
* The DC starting voltage can be in the menu if needed. /
Output levels
Rated power [VA] 5 000 6 500 7 500 9 000
Grid voltage [V] 400/230 (3/N/PE)
Rated current [A] 3 x 7,25 3 x 9,5 3 x 10,9 3 x 13,0
Max. rated current [A] 3 x 7,62 3 x 9,98 3 x 11,45 3 x 13,76
Rated frequency [Hz] 50/60
Make current [A] and ON duration [ms] 2,53 / 0,5
cos phi 0,30 inductive ...0,30 capacitive
Number of feed-in phases 3
THD [%] 3,85
Overvoltage safety class III
General electrical data
Effi ciency [%] 98,3 98,3 98,3 98,3
European effi ciency [%] 97,4 97,6 97,7 97,9
Internal consumption: night [W] 2
Feed-in starts at [W] 20
Circuit design Transformerless
Grid monitoring Country-specifi c
Ground fault monitoring Yes
Table 1: Electrical Data
