3.2 Design of the Product
Figure 2: Exterior and interior views of the Power Plant Controller
3.3 Operating and Display Elements of the Control Unit
Figure 3: Operating and display elements of the control unit
Position Designation
A Touch display*
* optional
B Control unit
C Connection area
Position Designation
A LEDs
B Device display
C Keypad
The network settings of the three LAN interfaces of the Power Plant Controller can be displayed
using the info button.
