HEIDENHAIN iTNC 530 479
13.1 Gener
a
l User P
a
ra
met
e
rs
Configure tool pocket
tables; Column
number in the pocket
table for
(To omit from the
table: enter 0) MP7267.0
Tool number – T: 0 to 7
MP7267.1
Special tool – ST: 0 to 7
MP7267.2
Fixed pocket – F: 0 to 7
MP7267.3
Pocket locked – L: 0 to 7
MP7267.4
PLC status – PLC: 0 to 7
MP7267.5
Tool name from tool table – TNAME: 0 to 7
MP7267.6
Comment from tool table – DOC: 0 to 7
Manual Operation
mode: Display of feed
rate MP7270
Display feed rate F only if an axis direction button is pressed: 0
Display feed rate F even if no axis direction button is pressed (feed rate defined via soft key F or
feed rate of the “slowest” axis): 1
Decimal character MP7280
The decimal character is a comma: 0
The decimal character is a point: 1
Display mode MP7281.0 Programming and Editing operating mode
MP7281.1 Program Run mode
Always display multiple line blocks completely: 0
Display multiline blocks completely if the multiline block is the active block: 1
Display multiline blocks completely if the multiline block is being edited: 2
Position display in the
tool axis MP7285
Display is referenced to the tool datum: 0
Display in the tool axis is referenced to the
tool face: 1
Display step for the
spindle position MP7289
0,1 °: 0
0,05 °: 1
0,01 °: 2
0,005 °: 3
0,001 °: 4
0,0005 °: 5
0,0001 °: 6
Display step MP7290.0 (X axis) to MP7290.8 (9th axis)
0.1 mm: 0
0.05 mm: 1
0.01 mm: 2
0.005 mm: 3
0.001 mm: 4
0.0005 mm: 5
0.0001 mm: 6
TNC displays, TNC editor
