398 10 Programming: Q Parameters
1
0
.8 A
d
ditional F
unctions
14 1 Center misalignment in ref. axis
2 Center misalignment in minor axis
15 - Direction of center misalignment compared with 0° position
Tool touch probe 130 20 1 Center point X-axis (REF system)
2 Center point Y-axis (REF system)
3 Center point Z axis (REF system)
21 - Probe contact radius
Measuring touch probe, 350 30 - Calibrated stylus length
31 - Stylus radius 1
32 - Stylus radius 2
33 - Setting ring diameter
34 1 Center misalignment in ref. axis
2 Center misalignment in minor axis
35 1 Compensation factor for 1st axis
2 Compensation factor for 2nd axis
3 Compensation factor for 3rd axis
36 1 Power ratio for 1st axis
2 Power ratio for 2nd axis
3 Power ratio for 3rd axis
Last touch point in TCH PROBE Cycle 0
or last touch point from manual
operating mode, 360 1 1 to 9 Position in the active coordinate system in axes 1 to 9
2 1 to 9 Position in the REF system in axes 1 to 9
Value from the active datum table in the
active coordinate system, 500 Datum
number 1 to 9 X axis to W axis
REF value from the active datum table,
501 Datum
number 1 to 9 X axis to W axis
Datum table selected, 505 1 - Acknowledgement value = 0: No datum table active
Return code = 1: Datum table active
Data from the active pallet table, 510 1 - Active line
2 - Palette number from PAL/PGM field
Group name, ID No. Number Index Meaning
