HEIDENHAIN iTNC 530 75
4.8 A
dding Comments
4.8 Adding Comments
Function
You can add comments to any desired block in the part program to
explain program steps or make general notes. There are three
possibilities to add comments:
Entering comments during programming
U U U U Enter the data for a program block, then press the semicolon key “;”
on the alphabetic keyboard—the TNC displays the dialog prompt
COMMENT ?
U U U U Enter your comment and conclude the block by pressing the END
key.
Inserting comments after program entry
U U U U Select the block to which a comment is to be added.
U U U U Select the last word in the block with the right arrow key: A
semicolon appears at the end of the block and the TNC displays the
dialog prompt COMMENT ?
U U U U Enter your comment and conclude the block by pressing the END
key.
Entering a comment in a separate block
U U U U Select the block after which the comment is to be inserted.
U U U U Initiate the programming dialog with the semicolon key “;” on the
alphabetic keyboard.
U U U U Enter your comment and conclude the block by pressing the END
key.
Functions for editing of the comment
Function Soft key
Jump to the beginning of the comment.
Jump to the end of the comment.
Jump to the beginning of a word. Words are to
be separated by a space.
Jump to the end of a word. Words are to be
separated by a space.
Switch between insert mode and overwrite
mode.
