XVI
7.1 Entering Miscellaneous Functions M and STOP ..... 182
7.2 Miscellaneous Functions for Program Run Control, Spindle and Coolant ..... 183
7.3 Miscellaneous Functions for Coordinate Data ..... 184
Programming machine-referenced coordinates: M91/M92 ..... 184
Activating the most recently entered datum: M104 ..... 186
Moving to position in an non-tilted coordinate system with a tilted working plane: M130 ..... 186
7.4 Miscellaneous Functions for Contouring Behavior ..... 187
Smoothing corners: M90 ..... 187
Insert rounding arc between straight lines: M112 ..... 188
Do not include points when executing non-compensated line blocks: M124 ..... 188
Machining small contour steps: M97 ..... 189
Machining open contours: M98 ..... 190
Feed rate factor for plunging movements: M103 ..... 191
Feed rate in millimeters per spindle revolution: M136 ..... 192
Feed rate at circular arcs: M109/M110/M111 ..... 192
Calculating the radius-compensated path in advance (LOOK AHEAD): M120 ..... 192
Superimposing handwheel positioning during program run: M118 ..... 194
Retraction from the contour in the tool-axis direction: M140 ..... 195
Suppressing touch probe monitoring: M141 ..... 196
Delete modal program information: M142 ..... 197
Delete basic rotation: M143 ..... 197
7.5 Miscellaneous Functions for Rotary Axes ..... 198
Feed rate in mm/min on rotary axes A, B, C: M116 ..... 198
Shorter-path traverse of rotary axes: M126 ..... 198
Reducing display of a rotary axis to a value less than 360°: M94 ..... 199
Automatic compensation of machine geometry when working with tilted axes: M114 ..... 200
Maintaining the position of the tool tip when positioning with tilted axes (TCPM*): M128 ..... 201
Exact stop at corners with nontangential transitions: M134 ..... 203
Selecting tilting axes: M138 ..... 203
7.6 Miscellaneous Functions for Laser Cutting Machines ..... 205
Output the programmed voltage directly: M200 ..... 205
Output voltage as a function of distance: M201 ..... 205
Output voltage as a function of speed: M202 ..... 205
Output voltage as a function of time (time-dependent ramp): M203 ..... 206
Output voltage as a function of time (time-dependent pulse): M204 ..... 206
