227 HEIDENHAIN TNC 310
1
4
.3
T
ec
hnical
Inf
o
rmation
14.3 Technical Information
TNC features
Description Contouring control for machines with:
control of 4 axes without spindle control or
control of 3 axes and with spindle control
Components Compact control with integrated flat-panel display (192 mm x 120 mm,
640 x 400 Pixel) and integrated machine control buttons
Data interface n RS-232-C / V.24
Simultaneous axis control for contour elements
n Straight lines: up to 3 axes
n Circles: up to 2 axes
n Helices: 3 axes
Background programming One part program can be edited while the TNC runs another program
Graphics n Programming graphics
n Test run graphics
File types n HEIDENHAIN conversational programming
n Tool table
Program memory n Battery back-up for approx. 6000 NC blocks (depending on length of
block), 128 KB
n Up to 64 files possible
Tool definitions Up to 254 tools in the program or in the tool table
Programming support n Functions for approaching and departing the contour
n HELP function
