Grass Valley DMC 1000 v.12.4 - Manual (Page 164)

164 DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Chapter 13 - Viewfinder menu
Record switch Enabled, Disabled Enables or disables the record switch under
the carrying handle. 0 Oper
IEEE 1394 1
IEEE 1394 Off, Exclusive, Both Selects IEEE 1394 interface operation mode:
Exclusive = playback via IEEE 1394 only;
Off = no playback via IEEE 1394;
Both = normal playback via IEEE 1394 and
monitoring on the side panel display. 1
Wireless 3
Wrx1 attenuation 0dB, +12dB Selects the input attenuation level of the
wireless microphone channel Wrx1. 3
Black calib 3
Start Off Starts the black calibration procedure. 3
Are you sure? No, Yes Select Yes to proceed and No to cancel. 3
Cal temp 63 Black calibration temperature in degrees
celsius (fixed value). 3
Diagnostics 3
PackageID Displays the identification of software
package that is currently installed in the
camcorder. 3
REV 3
Drive state OK, Error, Warning Displays the service status of the internal REV
drive. 3
Disk state OK, Error, Warning Displays the service status of the currently
mounted REV disk. 3
Power 3
Voltage Displays the voltage supplied to the
camcorder. 3
Power Displays the power used by the camcorder in
watts. 3
Power mode External, Battery Displays the power supply method. 3
Viewfinder menu item Values Description Level File
