Page 112: Setting up, Setting up vt220 -46
5-46
707096-005
iCON-XT Single Station Console Terminal User’s Manual
Setting up VT220
To setup a remote host:
1. Click the
button in the lower left-hand corner of the screen. The
application menu will appear.
2. Click VT220.
3. Click Setup.
Note:
When in full screen mode or when using a keyboard only (no mouse), the
Setup menu may be accessed with Ctrl-Shift-S.
4. Click Communications from the Setup menu. This screen will appear:
• Connection Type – Select either a LAN or Serial connection.
• LAN
– Host – Enter the Internet address of the VT220 server to which you wish to
connect, for example, 192.168.1.1.
– Port – If the host requires that a port number (other than port 23) be specified
when connecting, select the port number using the up and down arrows or by
typing the port in directly.
• Auto Connect – Select to auto connect at program start-up.
• Auto Login – Select to enable and configure auto login on connect.
• Auto Play Macro – Select the F# associated with the macro that should play upon
connection. The name of the macro (if previously named) will appear in the window
below the checkbox.
• Session Name – Enter the name to be displayed in the window title.
