Parameter Functions Settings
Factory
Setting
Customer
02-04 Forward/Reverse
Enable
00: Forward enabled
01: Reverse disabled
02: Forward disabled 00
02-05 2-wire/3-wire Operation
Control Modes
00: 2-wire (#1), FWD/STOP, REV/STOP
01: 2-wire (#2), RUN/STOP, REV/FWD
02: 3-wire 00
02-06 Line Start Lockout 00: Disabled
01: Enabled 01
02-07 Loss of ACI Signal 00: Decelerate to 0Hz
01: E.F.
02: Continue operation by the last
frequency command
01
a02-08 Start-up Display
Selection
Bit0~1: 00 = F LED
01 = H LED
10 = U LED (special display)
11 = Fwd / Rev
Bit2: 0 = Fwd LED / 1 = Rev LED
Bit3~5: 000 = 1st 7-step
001 = 2nd 7-step
010 = 3rd 7-step
011 = 4th 7-step
100 = 5th 7-step
Bit6~7: Reserved
00
a02-09 Special Display 00: A displays output current of AC drive
01: U displays DC-Bus voltage of AC drive
02: E displays RMS of output voltage
03: P displays feedback Signal
04: PLC display auto procedure state 00
a02-10 User Defined Coefficient 0.01~160.00 1.00
a02-11 Flying Start 00: Disable
01: Enable (Dc brake disabled) 00
a02-12 Flying Start Frequency 00: Trace from master frequency
command
01: Trace from maximum setting
frequency 01-00
00
a02-13 Master Frequency
Memory Setting
00: Do not remember the last known
frequency
01: Remember the last known frequency
01
Group 3 Output Function Parameters
Parameter Functions Settings
Factory
Setting
Customer
03-00 Multi-function Output
terminal 1
00
03-01 Multi-function Output
terminal 2
00
03-02 Multi-function Output
terminal 3
00
03-03 Multi-function Output
terminal 4
00
03-04 Multi-function Output
terminal 5
00: No function
01: Motor No.1
02: Motor No.2
03: Motor No.3
04: Motor No.4
05: Motor No.5
06: Motor No.6
07: Motor No.7
08: Motor No.8
09: Auxiliary 1 output
00
