Pattern
A pattern is a route that can be stored and recalled to execute repeatedly.
Pattern Line
Create up to eight Pattern paths with the camera. Using the left or right keys, select
an available line, then follow the steps below to start recording the pattern path.
Record Start
To record the PATTERN path.
1. Rotate the camera to the desired view area (for some protocols, you may need to
do it before entering the OSD), and press ENTER to build the pattern path using
the joystick on the control device. The percentage of the memory buffer will be
displayed on the screen.
2. Pan and tilt the camera to form a path.
Note
Beware of the memory size when building a pattern path. Once the buffer
percentage reaches 100%, recording will stop.
Record End
The cursor will be moved to RECORD END when building the pattern line. When the
setting is completed, press ENTER to save the path.
Run Pattern
After setting the pattern, select Run pattern to execute the pattern function.
PATTERN
PATTERN LINE 1
RECORD START ENTER
RECORD END ENTER
RUN PATTERN ENTER
EXIT YES
