Chapter 5: Monitor, Diagnostic, Maintenance
Monitor, Diagnostic, Maintenance
NGSME16T2H User Manual | 334
Mode
Indicates the filtering mode maintained per (VLAN ID, port number, Group Address)
basis. It can be either Include or Exclude.
Source Address
IP Address of the source. Currently, system limits the total number of IP source
addresses for filtering to be 128.
Type
Indicates the Type. It can be either Allow or Deny.
Buttons
Auto-refresh: Check this box to enable an automatic refresh of the page at regular
intervals.
Refresh: Refreshes the displayed table starting from the input fields.
|<<: Updates the table starting from the first entry in the MLD SFP Information Table.
>>: Updates the table, starting with the entry after the last entry currently displayed.
