Niveo Professional NGSME16T2H - Manual (Page 248)

Chapter 4: Feature Configuration - CLI
Featuring Configuration
– CLI
NGSME16T2H User Manual | 248
VLAN Configuration
Feature Command Line
VLAN Configuration
VLAN Membership Syntax:
VLAN Add | []
VLAN Name Add
Example:
VLAN>add 3 5-8 (Add port 5-8 to VLAN 3)
VLAN>name add vlan3 3 (vlan3 is the name of VLAN 3)
Port Configuration Syntax:
VLAN FrameType [] [all|tagged|untagged]
VLAN IngressFilter [] [enable|disable]
VLAN tx_tag [] [untag_pvid|untag_all|tag_all]
VLAN PortType []
[unaware|c-port|s-port|s-custom-port]
Example:
VLAN>framety 1-3 all
VLAN>ingr 1-3 en
VLAN>tx_t 1-3 untag_pvid
VLAN>portty 1-3 un
