Chapter 4: Feature Configuration - CLI
Featuring Configuration
– CLI
NGSME16T2H User Manual | 251
------------- ------------------------ --------
EthernetII ETYPE:0x808 E4
LLC_Other DSAP:0xff; SSAP:0xff L3
LLC_SNAP OUI-00:e0:2b; PID:0x1 S2
EthernetII ETYPE:0x800 E1
Group ID VID Ports
---------------- ---- -----
E4 10 1-8
E1 10 5-8
IP Subnet-based VLAN Configuration
IP Subnet-based
VLAN Configuration
Syntax:
VCL IPVlan Add []
[]
Parameters:
: Unique VCE ID for each VCL entry
: Source IP address and mask (Format:
a.b.c.d/n).
: VLAN ID (1-4095)
: Port list or 'all', default: All ports
Example:
VCL/IPVlan>add 1 192.168.10.0/24 10 1-10
Result:
VCE ID IP Address Mask Length VID Ports
------ --------------- ----------- ---- -----
1 192.168.10.0 24 10 1-10
