Chapter 5: Monitor, Diagnostic, Maintenance
Monitor, Diagnostic, Maintenance

NGSME16T2H User Manual | 287

Port VLAN ID

The VLAN ID that NAS has put the port in. The field is blank, if the Port VLAN ID is

not overridden by NAS.

If the VLAN ID is assigned by the RADIUS server, "(RADIUS-assigned)" is

appended to the VLAN ID. Read more about RADIUS-assigned VLANs here.

If the port is moved to the Guest VLAN, "(Guest)" is appended to the VLAN ID. Read

more about Guest VLANs here.

Port Counters

EAPOL Counters

These supplicant frame counters are available for the following administrative

states:

Force Authorized

Force Unauthorized

Port-based 802.1X

Single 802.1X

Multi 802.1X

EAPOL Counters

Direction

Name

IEEE Name

Description

Rx

Total

dot1xAuthEapolFramesRx

The number of valid EAPOL frames of any type

that have been received by the switch.

Rx

Response

ID

dot1xAuthEapolRespIdFramesRx

The number of valid EAPOL Response Identity

frames that have been received by the switch.

Rx

Responses dot1xAuthEapolRespFramesRx

The number of valid EAPOL response frames

(other than Response Identity frames) that have

been received by the switch.

Rx

Start

dot1xAuthEapolStartFramesRx

The number of EAPOL Start frames that have

been received by the switch.

Rx

Logoff

dot1xAuthEapolLogoffFramesRx

The number of valid EAPOL Logoff frames that

have been received by the switch.

Rx

Invalid

dot1xAuthInvalidEapolFramesRx

The number of EAPOL frames that have been

received by the switch in which the frame type is
