XPA200-7984-I-OPT1, X-Band SSPA System Operation
XPA200-7984-I-OPT1, Rev.2 3-6
LEGEND
------------------------
------------------------
KEY-PAD
RIGHT
LEFT DOWN
UP
ENTER
CLR
DISPLAY
ENTER
(See Para. 3.3.4)
DOWN
UP
---------SELECT---------
--CURRENT-FAULTS-MENU---
(See Para. 3.3.4.1)
-----28-VDC-PS-=-OK-----
--10VPS1=OK--10VPS2=OK--
POWER-FAULTS:----+12V=OK
-12V=OK--VCC=OK---5V=OK-
(See Para. 3.3.4.1)
---AMPLIFIER-TEMP-=-OK--
-FAN-1-=-OK--FAN-2-=-OK-
(See Para. 3.3.4.3)
(See Para. 3.3.4.2,
Para. 3.3.4.3)
--M&C-PROCESSORS-=-OK---
------------------------
Figure 3-4. Currents Faults Menu Commands
