XPA200-7984-I-OPT1, X-Band SSPA Introduction
XPA200-7984-I-OPT1, REV.3 1-7
1.9 Front Panel Display
The front panel display is a two line by twenty-four
character, LCD display. Each configuration function, or
operating mode, is shown on the display when the operator enters
a command into the key-pad on the front panel.
1.10 Front Panel Test Point Samples
Two test point connections are located on the front panel
for monitoring the RF input and the RF output. A type N female
connector is provided for the RF sample test points.
1.11 Rear Panel Connections
The following is a list of the connectors on the rear panel:
! Connector J1: SSPA RF Input (RF in).
! Connector J2: SSPA RF Output (RF output).
! Connector J3: AC Prime Power Input (AC in).
! Connector J4: Cust. Discrete Control (Discrete Control).
! Connector J5: Combiner Interface.
! Connector J6: COM1 Port (RS-232C/RS-485) (COM1).
! AC Power On / Off Switch.
