XPA200-7984-I-OPT1, X-Band SSPA System Operation
XPA200-7984-I-OPT1, Rev.2 3-2
Table 3-1. Operating Functions - Front Panel
Item Functional Description Reference
Designation
Key-Pad;
ENT key
Enters commands into the
converter.
ENT
Key-Pad;
CLR key
Clears commands and data selected
and not entered.
CLR
Key-Pad;
Right Arrow key
Selects functions and the menu
operating data.
Right Arrow
Key-Pad;
Left Arrow key
Selects functions and the menu
operating data.
Left Arrow
Key-Pad;
Up Arrow key
Selects the operating menu and
data values.
Up Arrow
Key-Pad;
Down Arrow key
Selects the operating menu and
data values.
Down Arrow
LCD Display Displays commands and data entered
into the key-pad.
STATUS Indicator,
Green
Prime power is applied when the
light is on.
POWER ON
STATUS Indicator,
yellow
Transmit function operating when
the light is on.
TRANSMIT ON
STATUS Indicator,
yellow
In Remote Control Mode when the
light is on.
REMOTE
STATUS Indicator,
yellow
Operating on-line to receive
data when the light is on.
ON LINE
STATUS Indicator,
Red
Fault condition exists when the
light is on.
FAULT
STATUS Indicator,
Red
Faults stored and logged
when the light is on.
STORED
FAULT
INPUT SAMPLE Type N connector test point
to sample RF input.
SAMPLE INPUT
OUTPUT SAMPLE Type N connector test point to
sample RF output.
SAMPLE OUTPUT
