XPA200-7984-I-OPT1, X-Band SSPA Introduction
XPA200-7984-I-OPT1, REV.3 1-3
1.3 Specifications
The following are the design, operating and environmental specifications
for the XPA200-7984-I X-Band Solid State High Power Amplifier (SSPA).
Output Front Panel
Frequency 7.900-8.400 GHz Display 24 x 2 LCD
Power 53.0dBm min. @ 1dB Comp. Data Entry Cursor Control Keypad
(see Note 1) Output Sample Type N,50 Ohms,-40dBc
Mute -80dB Input Sample Type N,50 Ohms,-20dBc
VSWR 1.25:1 Max.
Connector CPR-112G Waveguide Flange
Gain Remote Control
Linear 62dB min, 67dB typ. Comm Port RS-485 or RS-232C
Adjust 20dB in 0.25dB Steps Protocol Comtech ASCII or Emul.
Per 500MHz +.75dB
Per 40 MHz +.25dB Alarms
+0 - +50C +0.50dB @ center Freq. Summary Fault Form C
±1.00dB @ full band
LED
Power Green
Fault Red
Stored Fault Red
Third Order Intermod. Tx ON Yellow
Intercept +60.5dBm Min.,+62.0dBm Typ. Online Yellow
Products -30dBc typ., -25dBc max @ Remote Yellow
3 dB total back off
(two tones, ª f= 1MHz)
Mechanical
AM to PM Conversion Height 12.25 inches
2.0 degrees typ., 3.0 max @ rated output Width 19 inches
Depth 24 inches
Weight 100 lbs.
Group Delay
Linear +0.03ns/MHZ Environmental
Parabolic +0.003ns/MHz 2 Temperature 0 to +50C Operation
Ripple 1.0ns Peak-to-Peak (See Note 1)
-40 to +70C Storage
Humidity 10-95% Noncond. Oper.
Spurious 0-100% Noncond. Stor.
Carrier Related -65dBc Shock Normal Commercial
Line Related -50dBc Shipping & Handling
Input
Impedance 50 Ohms Power Requirements
Noise Figure 10dB Typ.,15dB Max. 115 VAC, 47-63 Hz, 2600 VA
VSWR 1.25:1 Max.
Connector Type N
Note 1: P1dB only guaranteed 0 to 40C. Operation above 40C not recommended.
