Comtech EF Data XPA-200 User Manual
Page 18
XPA200-7984-I-OPT1, X-Band SSPA
Introduction
XPA200-7984-I-OPT1, REV.3
1-2
POWER
AMPLIFIER
AS/0558
RF INPUT
RF OUTPUT
MONITOR & CONTROL
AS/0200
+5V
-5V
AUX. PS & SWITCH
CONTROL
AS/0206
+12V
-12V
CONTROL
& MONITOR
PS # 2 28Vdc
PS #1 10Vdc
+10Vdc
-5Vdc Interlock
FAN2
FAN1
Prime
Power
Input
PS #2 10Vdc
Figure 1.1 FUNCTIONAL BLOCK DIAGRAM
