XPA200-7984-I-OPT1, X-Band SSPA System Operation
XPA200-7984-I-OPT1, Rev.2 3-3
(See Figure 3-2)
---------SELECT---------
---STORED-FAULTS-MENU ---------SELECT---------
----CONFIGURATION-MENU--
---------SELECT---------
--MONITOR-STATUS-MENU---
---------SELECT---------
--CURRENT-FAULTS-MENU---
---------SELECT---------
-UTILITY-FUNCTIONS-MENU-
----XPA200-7984-I-----
SW VER 1.02 SNXXX
ENTER
(See Figure 3-3)
(See Figure 3-4)
(See Figure 3-5)
(See Figure 3-6)
LEGEND
------------------------
------------------------
KEY-PAD
RIGHT
LEFT DOWN
ENTER
CLR
DISPLAY
UP
3.3 Operation
Local operation of the 200 watt, X-Band SSPA is controlled by
operator input commands initiated through the six button key-pad on
the front panel. The key-pad is the local operator's interface to
control, configure and monitor the status of the SSPA. Operator
inputs and commands entered into the key-pad are displayed by the
front panel twenty-four character, two line, LCD display. See Section
5.0 for Remote Control Operation.
There are five operating command functions: Configuration,
Monitor Status, Currents Faults, Stored Faults and Utility Functions.
A flow chart for selecting the commands, operating menus, and data
inputs is shown in Figures 3-1 through 3-6.
Figure 3-1. SSPA Operating Command Functions
