XPA200-7984-I-OPT1, X-Band SSPA Introduction
XPA200-7984-I-OPT1, REV.3 1-11
1.11.4 AC Prime Power Input Connector, J3
The AC prime power input connector, J3, is a 3 pin circular
connector, type CA3102E20-19PB FMLB A. The ground connector, pin
A, is of the first make, last break type. The pin-out
specifications are contained in Table 1-4. A mating connector of
type CA3106E20-19SB is included for the customer.
Table 1-4.
J3, AC Prime Power Input Connector
Pin # Description
A Ground
B Neutral
C Line
1.12 Prime Power Switch
The on/off prime power switch is located on the rear of the
chassis adjacent to the prime power input connector. The circuit
breaker is rated for 40 Amps.
