XPA200-7984-I-OPT1, X-Band SSPA Introduction
XPA200-7984-I-OPT1, REV.3 1-10
1.11.3 Combiner Interface, Connector J5
The Redundant Loop interface connector, J5, is a 19 pin
circular connector, type MS3112E14-19S. The pin-out
specifications is contained in Table 1-3 The mating connector is
a MS3116F14-19P.
Table 1-3.
J5, Combiner Interface Connector Pin-Out
Pin # Description Pin # Description
A Inhibit Command L not used
B VPC A+B->Antenna M not used
C not used N not used
D not used P not used
E VPC Output Common R not used
F VPC A(B)->Antenna S Local SumFlt Common
G not used T Local SumFlt NO
H Inhibit Common U not used
J not used V not used
K not used
