5.8.3 RJ-45 Connector for Console Port
The RJ-45 female connector marked
CSL
provides a physical port for attachment of the
console cable. It is a dedicated port with autosensing DTE/DCE mode and autobaud.
The following table describes the RJ-45 pinout for the console port.
Pin No. Usage Description
1 RTS Request To Send
2 DTR DTE Ready
3 TXD Transmitted Data
4 SGND Signal Ground
5 DCD Carrier Detect
6 RXD Received Data
7 DSR DCE Ready
8 CTS Clear To Send
Table 5-8: RJ-45 pinout for console port
