SDM-9600 with SDM-9606 Blades Hardware Installation Guide
5-2 Memotec Inc.
5.1 SDM-9600 Chassis
5.2 SDM-9606 Blade
5.3 Optional Hardware
Item Details
Base unit chassis with 5 front slots for
SDM-9606 blades “Base Unit Chassis” on page 5-3
2 redundant -48VDC power input mod-
ules “Power Input Modules” on page 5-4
Fan unit, with removable air filter “Fan Unit” on page 5-5
Table 5-1: Feature items for the SDM-9600 chassis
Item Details
1 console port, with console cable “Console Port” on page 5-13
2 Ethernet ports (require customer-sup-
plied LAN cables and snap-on ferrites) “Ethernet Ports” on page 5-9
6 built-in E1/T1 interfaces (require cus-
tomer-supplied RJ-48 cables and snap-on
ferrites) “E1/T1 Digital Interfaces” on
page 5-15
Table 5-2: Feature items for the SDM-9606 blade
Item Details
DSP modules: high-density “DSP Modules” on page 5-11
Table 5-3: Feature items for optional hardware
