Page 72
SDM-9600 with SDM-9606 Blades Hardware Installation Guide
5-10
Memotec Inc.
5.6.4
RJ-45 Connector for Ethernet LAN Port
The RJ-45 female connectors marked
ETH
on the SDM-9606 blade provide two physical
LAN ports for attachment to the local LAN hub (10/100/1000Base-T, MDI connection).
The following table describes the RJ-45 pinout for a LAN port.
Pin No.
Usage
Description
1
TX+
Transmit (+) Output
2
TX-
Transmit (-) Output
3
RX+
Receive (+) Input
4
–
(not used)
5
–
(not used)
6
RX-
Receive (-) Input
7
–
(not used)
8
–
(not used)
Table 5-7: RJ-45 pinout for Ethernet LAN port
