1.3 Product Overview
1.3.1 SDM-9600 Chassis
The NetPerformer SDM-9600 is a high-end chassis based on a standardized platform
architecture for carrier-grade telecommunication applications. It is ideal for large-scale
network applications such as GSM using point-to-point E1/T1 circuits, transport through
IP (terrestrial or satellite) or satellite Single Channel Per Carrier (SCPC) connections, and
Voice over IP (VoIP). Voice/data over PowerCell applications can use IP or WAN
connections and are able to integrate SCPC on digital or serial interfaces.
• PICMG 3.0 standard rack solution
• 19" rack-mountable
• -48 VDC (dual feed)
• Maximum 5 blades, loaded from the front
NOTE:
All slots on the SDM-9600 must be installed with the same type of blade, in
this case, the SDM-9606.
• Hot swappable components
• Removable fan control module and air filter.
The basic software set provides support of PowerCell Voice and Data (including legacy
user data) and IP routing over Ethernet, serial or digital ports using PPP or Frame Relay
RFC-1490. Optional software licenses can be procured for support of GSM A-bis/ter,
SkyPerformer satellite access and TCP Acceleration.
1.3.2 SDM-9606 Blade
• Loads into front slots (maximum 5)
• Each blade has 6 built-in T1/E1 universal digital ports in the front (NT hard-
wired)
• Can be loaded with 1 DSP module
• Each blade has a capacity of up to 120 digital telephony channels
• A fully loaded SDM-9600 supports 600 simultaneous voice calls
• 1 RJ-45 console port
• 2 10/100 Ethernet ports
• Hot swap capability and power management control
• GSM and ATM capable.
