SDM-9600 with SDM-9606 Blades Hardware Installation Guide
4-4 Memotec Inc.
4.3 Installing or Upgrading the DSP Modules
Follow the procedure in this section for both installation and upgrade of a DSP module on
the SDM-9606 blade.
You need to have a DSP module to support voice/fax channels and GSM TRXs. This DSP
module is ordered separately from the unit and must be installed when you set up the
hardware at your site. For ordering information, refer to
“Sales Contacts” on page 1-11 .
4.3.1 Location of DSP Socket on the SDM-9606 Blade
Figure 4-2: DSP Socket on the SDM-9606 Blade
DSP Socket
