SDM-9600 with SDM-9606 Blades Hardware Installation Guide
4-22 Memotec Inc.
4.11 Connecting the LAN Hub
You must provide a standard straight through Ethernet 802.3 LAN cable (10/100/
1000BaseT, RJ-45M to RJ-45M) for connection to each LAN port.
NOTE: LAN cables are not provided with the SDM-9606 product package.
To connect the SDM-9606 blade to a LAN hub:
1. Connect one end of the LAN cable to one of the Ethernet LAN ports on the blade,
labelled
ETH 1
and
ETH 2
. Refer to Figure 5-5 .
2. Connect the other end of the LAN cable to one of the 10/100/1000BaseT ports on
your local LAN hub.
3. The link is up when the
LNK
LED is on. The LED color indicates the speed of the
LAN connection:
- Amber: 100 Mbps
- Green: 10 Mbps.
