SDM-9600 with SDM-9606 Blades Hardware Installation Guide
3-2 Memotec Inc.
3.1 Selecting a Location
To ensure that the SDM-9600 functions properly, you should install the unit in an
appropriate location which satisfies certain criteria for size, connection distance and
ambient environment.
3.1.1 Rack Requirements
The SDM-9600 chassis is designed with rackmount ears for installation in a rack:
• Standard 19" rack
• Near an easily accessible -48 VDC power supply.
• To ensure proper ventilation of the SDM-9600 and its components, leave 5 cm (2
inches) of unobstructed space around the unit chassis.
CAUTION: Unit must be installed in a restricted access location.
3.1.2 Distance Requirements
The SDM-9600 unit should be no more than 2 meters (approx. 6 feet) away from:
• A power supply appropriate to the type of power module on the unit: -48 VDC, 3
Amps maximum.
• An independent Ground.
WARNING:
Ensure that the unit is independently grounded with a
wire from Ground securely attached to the ground lug on the SDM-
9600 chassis. The ground lug is located below the
POWER ON
LED at the front of the chassis.
3.1.3 Environmental Requirements
For trouble-free operation of the SDM-9600 its location must satisfy the following
environmental criteria:
• Operating temperature: 0 C to 45C (32F to 113F)*
• Storage temperature: -20 C to 65C (-4F to 149F)
• Relative humidity: 10% to 95%, non-condensing
