- 75 -
PS-8810
DIGITAL SIGNAL PROCESSOR
Processing Functions Input/Output Matrix
The CobraNet input channels have the CobraNet logo and are
coloured pink. There are no overall channel controls available to
these inputs.
The crosspoint controls in the Matrix itself enable an amount of
signal to be routed using the black level control - control range is
from “Off” to +20dB. Exclusive assignment of a particular input to
output is attained by pressing the button at the crosspoint between
the required channels. In this situation the level controls for all
inputs in that output channel become greyed out and are inactive.
