User’s Guide
BSS Audio MC-1
Stand-Alone Media Converter
• Gigabit Ethernet
•Copper to Fiber
•1000Base-T to 1000Base-SX/LX
BSS Audio MC-1 Gigabit Ethernet media
converter connects 1000Base-T
shielded or unshielded twisted-pair copper
cable to 1000Base-SX or 1000Base-LX, fiber-
optic cable. MC-1 is a stand-
alone media converter
Installation . . . . . . . . . . . . . . . . . .3
Operation . . . . . . . . . . . . . . . . . . .7
Cable Specifications . . . . . . . . . . .9
Technical Specifications . . . . . . .11
Troubleshooting . . . . . . . . . . . . .12
Contact Us . . . . . . . . . . . . . . . . .13
Compliance Information . . . . . . .15
MC-1 RJ-45 1000Base-T
100 m (328 ft)*
SC, 1000Base-LX, 1310 nm single mode
10 km (6.2 miles)*
*Typical maximum cable distance. Actual
distance is dependent upon the physical
characteristics of the network installation.
