- 119 -
PS-8810
DIGITAL SIGNAL PROCESSOR
Specifications
+5VDC and +10VDC outputs are provided. The total output
current is limited to 1A
less than 0.1V
10V (via internal pull-up)
Output Current is limited to 10mA max per pin
greater than 50kOhm
less than 0.5V
greater than 5V
0 to 10V (for inputs 9-16 only)
25V
13 pounds, 4 ounces (6.1 kg)
Width: 19-inch (483-cm) standard rack mount (EIA RS-310-B)
Depth: 16-inch (40.6-cm) behind mounting surface
Height: 3.5-inches (8.9-cm)
Control Port:
Power Supply:
Outputs:
Logic Low:
Logic High:
Inputs:
Input Impedance:
Logic Low:
Logic High:
Analogue Range:
Max Input Voltage:
Weight:
Dimensions:
Mechanical:
