Paxton Superchargers Ford 5.0L Mustang GT - Manual (Page 7)

P/N: 4809664 v3.1, 06/12/2012
©2012 Paxton Automotive
All Rights Reserved, Intl. Corp. Secured
vii
PART NUMBER DESCRIPTION QTy. PART NUMBER DESCRIPTION QTy.
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or dam-
aged parts immediately.
008569 1 yR S/C STRT INFO PKG ASy PAX 1
009030 S/C LUBE, BOTTLED, PAXT 3-PACK 1
1016177 S/C ASy, NOVI 2200SL, 2011 MSTG 1
3863515 DECAL, PAXTON COLOR 9" X 3" 1
4809664 INSTR MAN, PAX, 2011 MSTG GT 1
4FQ111-013 MNTG BRKT ASy, 2011 MSTG 5.0 1
2A017-875-27 SPACER, .875OD X .404ID X 1.895L 4
2A017-876-13 SPACER, .875OD X .328ID X 2.730L 2
2A017-876-14 SPACER, .875OD X .328ID X 2.058L 2
2A017-876-15 SPACER, .875OD X .328ID X 2.146L 1
2A017-876-16 SPACER, .875OD X .328ID X 1.928L 1
2A046-031 BELT, 6 RIB X 103.3 EFF. LENGTH 1
4FQ010-013 MNTG PLT, OUTER, 2011 MSTG 5.0 1
4FQ010-023 MNTG PLT, INNER, 2011 MSTG 5.0 1
4FQ016-010 PULLEY, WATER PUMP, 2011 MSTG GT 1
4FQ017-021 SPCR, .875/1.25OD X .328ID X 1.782L 1
4FQ017-031 SPCR, .875ODX.404IDX.363L W/.66 PLT 4
4GF016-161 PULLEY, 3" IDLER, GROOVED, MOD 1
4PCS016-160 PULLEY, IDLER, SRT10 TRUCK 1
4TX016-150 IDLER, 2.75 DIA, SMOOTH, 7 RIB 2
7A375-126 3/8-16 X 1.25 HHCS, GR8, PLT 5
7A375-352 3/8-16 X 3.5" HX HD GR8 5
7C080-064 M8 X 1.25 X 65MM BHCS CL10.9 1
7C080-081 M8 X 1.25 X 80 HXHD CL10.9 1
7C080-101 M8-1.25 X 100 BHCS CL10.9 1
7C080-200 M8-1.25 X 200MM STUD, 35MM THREAD 2
7F008-021 NUT, M8 X 1.25, SERRATED FLG 2
7J312-000 5/16 FLAT WASHER-SAE 3
7K375-040 3/8 AN960 FLAT WASHR PLATED 9
7K375-050 3/8 WASHER, STAINLS, .030THK 1
2A017-875-28 SPACER, .875OD X .404ID X 2.73 LONG 1
4FQ112-010 AIR INLET ASy, 2011 MSTG 5.0 1
008359 DECAL, INLET, 2011 MSTG GT PAX 1
4FQ012-010 INLET DUCT, 2011 MSTG 5.0 CENT 1
5W001-039 1" HEAT SHRINK TUBING 3 IN
5W001-082 SLEEVE, FLEX BRAID, Ø.75" NOM. .75 FT
7J006-093 6MM WASHER, PLATED 2
7P375-039 3/8 NPT X 5/8" BARB 90° 1
7P375-106 PCV VALVE, FORD, 3/8" HOSE 2
7P625-004 5/8 TEE #28634 1
7P625-091 5/8 X 5/8 X 90° BARB ELBOW, PLASTIC 1
7P625-377 5/8" -3/8" RDCR BRB BLK PLASTIC 1
7PS375-100 SLEEVE, 3.75 X 1.0 3-PLY MATTE BLK 1
7PS400-225 BUMP SLEEVE, Ø4X2.25, BLACK 1
7PS400-351 SLEEVE,4.0 X 3.5 X 2.35L 1
7R002-056 #56 SAE TYPE F SS HOSE CLAMP 1
7R002-064 #64 SAE TYPE F SS HOSE CLAMP 3
7R004-002 STEPLESS CLAMP, 17.0-70 2
7R004-004 STEPLESS CLAMP, 1.0 OD HOSE 6
7U030-066 HOSE, 5/8" X 90°, 3" X 3" 1
7U032-016 3/8" EFI FUEL HSE HI-PSR 0.5 FT
7U033-000 5/8" PCV HOSE 2 FT
7U100-055 TIE WRAP, 7.5" NYLON 6
8A004-007-1 BLK OFF PLT, VORT, FORD SLT MAF 1
8H040-185 AIR FILTER, 2011 MSTG GT PANEL 1
4FQ114-010 CLNG SyS MOD ASy, 2011 MSTG GT 1
4FE014-010 RADIATOR PIPE-STAINLESS 1
4FQ010-030 BRKT, CLNT RES, 2011 MSTG GT 1
4FQ010-040 BRKT B, CLNT RES, 2011 MSTG GT 1
4FQ010-050 BRKT, FAN MODULE, 2011 MSTG GT 1
4FQ010-060 AIR DAM, FAN SHROUD, 2011 MSTG GT 2
4FU014-060 WATER PIPE, Ø1.5 X 90, 07+ MUST GT 1
5W001-085 SLEEVE, FLEX BRAID, Ø1.5" NOM 1 FT
7A250-051 1/4-20 X .50 HHCS GR5 ZINC PLTD 4
7C006-038 6-32 X .375 BHCS, 18-8 SS 12
7F006-001 6-32 HEX NUT, NYLOCK GR5 12
7J006-093 6MM WASHER, PLATED 4
7P250-045 1/4 MALE NPT X 3/8 MALE BARB 1
7P312-050 5/16 UNION HOSEMENDER 2
7P375-050 3/8" HOSE UNION, BRASS 2
7P375-098 TEE, 3/8" INCH, PLASTIC 1
7R002-010 #10 SAE TYPE F SS HOSE CLAMP 2
7R002-028 #28 SAE TYPE F SS HOSE CLAMP 6
7R004-001 STEPLESS CLAMP, 15.7-70 4
7R004-002 STEPLESS CLAMP, 17.0-70 9
7R004-007 STEPLESS CLAMP, 28.6 X 7MM WIDE 1
7U030-056 3/8 PCV/VAC RUBBER HOSE 2.5 FT
7U031-016 5/16" PCV/VAC RUBBER HOSE 1 FT
7U133-050 1.5" X 90° HOSE, LONG LEG 1
8N055-080 TANK, RAD OVERFLOW, 05 MUST 1
7U038-000 3/4" HEATER HOSE 36 IN
4FQ212-030 DISCh ASy, 2011 MSTG 5.0 1
2A017-876-02 SPACER, .875 OD X 1.565 LONG 4
4FQ012-040 DISCH TUBE B, 2011 MSTG GT 1
4FQ012-050 DISCH TUBE C, 2011 MSTG GT 1
4FQ017-011 SPACER, TB, 1.25, 2011 MSTG GT 1
4FQ112-030 DISCH TUBE A, 2011 MSTG GT, BYPS 1
4GE012-030 DISCH TUBE A, 6.2 CAMARO SAT 2
4PGM012-010 ELBOW, REDUCER, 4X3.5, CAST 1
7C040-008 M4-.7X8MM SCHD SS 2
7C060-080 M6 X 1.00 X 80 SHCS CL 12.9 4
7C080-066 M8 X 1.25 X 65 HXHD CL10.9 4
7F008-021 NUT, M8 X 1.25, SERRATED FLG 4
7J006-093 6MM WASHER, PLATED 4
7J312-875 5/16" WASHER, CUSTOM 8
7P062-187 1/16 NPT X 3/16 HOSE BARB 1
7P375-250 3/8"X3/8"X1/4"MALE BARB TEE 1
7P500-001 1/2" HOSE UNION 4
7P500-016 TEE, .5 X .5 X 1/16 NPT, METAL 1
7PS300-275 REDUCER, BLK Ø3.0-Ø2.75 1
7PS300-300 SLEEVE, BLACK, 3.00D X 3.00 3
7PS300-301 BUMP HOSE, 3.00D X 3.00L 1
7PS350-200 SLEEVE, BLACK 3.50"IDX2.0"LG 1
7PS350-304 SLEEVE, BLK, 3.5" X 3.0"L 1
7PS400-300 SLEEVE, BLK, 4.0" X 3.0"L 1
7PS400-301 REDUCER, HUMP, PROG 3.0 X 4.0 1
7R002-044 #44 SAE TYPE F SS HOSE CLAMP 1
7R002-048 #48 SAE TYPE F SS HOSE CLAMP 9
7R002-052 #52 SAE TYPE F SS HOSE CLAMP 4
7R002-056 #56 SAE TYPE F SS HOSE CLAMP 5
7R002-064 #64 SAE TYPE F SS HOSE CLAMP 3
7R004-687 STPLS CLAMP, 13/16", 1 EAR 8
7S300-003 RUBBER ELBOW 3" MODIFIED 2
7S350-120 ELBOW, Ø3.5", 120º, 2.5" C.L. 1
7S350-220 ASM, FLOW STRAIGHTENER, 3.5 OD 1
7U012-238 O-RING, 2-238, 3.484ID X .139 1
7U030-187 VACUUM HOSE, 3/16 48 IN
7U030-036 1/2" OIL DRAIN HOSE 3 FT
8A003-071 MAF, 3.8ID, 05 MSTG GT 1
8H040-175 FILTER, 1.75"ID, RACE BYPS 1
5A003-070 ECU REFLASh TL, 2011 MSTG GT 1
8D204-010 RACE ByPASS VALVE-BLACK/SAT 1
8F160-046 FUEL INJ ASy, 2011 MSTG GT 1
4FQ017-041 SPCR, FUEL RAIL, EV14, 2011 MSTG GT 4
8F060-046 FUEL INJ, 47LB EV14 8
7C060-091 M6 X 1.0 X 90MM SHCS PLT GR12.9 4
7J250-001 1/4 WASHER, SAE, PLATED 4
8PN101-050 WELDED CAC CORE ASy 1
PaxFreehandBW/Lg-2.eps—10/04/04
PARTS LIST
2011-12 Ford Mustang GT
Part No. 1001863SL
