Reconnect the upper radiator hose quick release

to the “Y” fitting on the thermostat housing.

Confirm all hose connections are secure.

Attach the open end of the new ¾” coolant hose

(with OEM abrasion sleeve attached) previously

connected to the replacement engine coolant res-

ervoir, to the driver side heater tube located on

the front of the engine. (See Figs. 10B-1, 10B-2)

Refill the engine cooling system via the replace-

ment coolant reservoir with the previously-drained

coolant. Filter if needed, ensuring no contami-

nants enter the cooling system. The coolant res-

ervoir should be approximately 1/2 full. Do not

overfill. Close the reservoir with the OEM cap

from the OEM coolant reservoir.

10. MISCELLANEOUS REASSEMBLy

NOTE: Periodically check the coolant level

once the car is running and the cooling sys-

tem purges.

Fig. 10B-1: Ø¾” Coolant Hose

Fig. 10B-2: Ø¾” Coolant Hose
