Doremi ShowVault / IMB - Manual (Page 55)

____________________________________________________________________________________
SHV.OM.001293.DRM Page 55 of 146 Version 1.5
Doremi Labs

The following pop-up window will appear (Figure 55):
Figure 55: Macro Editor GUI
– Library Automation Configuration

Select the desired action and click the Ok button, or Cancel to cancel this command.
6.2.8 Resulting Macro Setting

After inserting the three action s “Delay 1 seconds”, “GPO #4 Pulse at 200 ms” and
“Playback: PLAY” in the Macro “Test_Macro” as demonstrated above, the right part of
the Automation Cue tab will display the added actions as presented below (Figure 56):
Figure 56: Example of Macro Actions Window Updated

Click the Save button to save the Test_Macro settings.

Enter the password to save settings and proceed.
List of actions
inserted into the
Test element
Arrow
buttons
Edit Action
button
Save
button
Remove
button
Selected Macro
automation
