2–32 Chapter 2: Board Components
Components and Interfaces
Arria II GX FPGA Development Board, 6G Edition Reference Manual © July 2010 Altera Corporation
The HSMC interface has programmable bi-directional I/O pins that can be used as
2.5-V LVCMOS, which is 3.3-V LVTTL-compatible. These pins can also be used as
various differential I/O standards including, but not limited to, LVDS, mini-LVDS,
and RSDS with up to 17 full-duplex channels.
1 As noted in the High Speed Mezzanine Card (HSMC) Specification manual, LVDS and
single-ended I/O standards are only guaranteed to function when mixed according to
either the generic single-ended pin-out or generic differential pin-out.
Table 2–36 lists the HSMC port A interface pin assignments, signal names, and
functions.
Table 2–36. HSMC Port A Pin Assignments, Schematic Signal Names, and Functions (Part 1 of 4)
Board
Reference Description
Schematic Signal
Name I/O Standard
Arria II GX
Device
Pin Number
J2.17 Transceiver TX bit 3 HSMA_TX_P3
1.5-V PCML
K31
J2.18 Transceiver RX bit 3 HSMA_RX_P3 L33
J2.19 Transceiver TX bit 3n HSMA_TX_N3 K32
J2.20 Transceiver RX bit 3n HSMA_RX_N3 L34
J2.21 Transceiver TX bit 2 HSMA_TX_P2 M31
J2.22 Transceiver RX bit 2 HSMA_RX_P2 N33
J2.23 Transceiver TX bit 2n HSMA_TX_N2 M32
J2.24 Transceiver RX bit 2n HSMA_RX_N2 N34
J2.25 Transceiver TX bit 1 HSMA_TX_P1 P31
J2.26 Transceiver RX bit 1 HSMA_RX_P1 R33
J2.27 Transceiver TX bit 1n HSMA_TX_N1 P32
J2.28 Transceiver RX bit 1n HSMA_RX_N1 R34
J2.29 Transceiver TX bit 0 HSMA_TX_P0 T31
J2.30 Transceiver RX bit 0 HSMA_RX_P0 U33
J2.31 Transceiver TX bit 0n HSMA_TX_N0 T32
J2.32 Transceiver RX bit 0n HSMA_RX_N0 U34
J2.33 Management serial data HSMA_SDA
2.5-V
R1
J2.34 Management serial clock HSMA_SCL T1
J2.35 JTAG clock signal JTAG_TCK L24
J2.36 JTAG mode select signal JTAG_TMS N25
J2.37 JTAG data output JTAG_HSMA_TDO —
J2.38 JTAG data input JTAG_HSMA_TDI —
J2.39 Dedicated CMOS clock out HSMA_CLKOUT0 P10
J2.40 Dedicated CMOS clock in HSMA_CLKIN0 AP17
J2.41 Dedicated CMOS I/O bit 0 HSMA_D0 L1
J2.42 Dedicated CMOS I/O bit 1 HSMA_D1 R6
J2.43 Dedicated CMOS I/O bit 2 HSMA_D2 K1
J2.44 Dedicated CMOS I/O bit 3 HSMA_D3 M1
