Parameters
ALM
DSP
Blocks
Memory Registers
f
MAX
(MHz)
Channel Wires Filter Type Coefficients M10K M20K Primary Secondary
1 — Decimation — 219 3 0 — 159 23 28
9
1 super
sample
— Decimation — 404 20 0 — 398 43 28
8
1 super
sample
— Decimation Write 503 20 0 — 774 46 25
6
1 — Decimation Write 312 3 0 — 208 26 28
9
1 Half
Band
— Decimation — 234 3 0 — 192 29 28
9
1 Half
Band
— Decimation Write 323 3 0 — 228 32 28
8
1 — Fractional
Rate
— 422 3 0 — 723 94 31
0
1 — Fractional
Rate
Write 516 3 0 — 787 86 29
2
1 Half
Band
— Fractional
Rate
— 195 2 0 — 251 12 26
1
1 Half
Band
— Fractional
Rate
Write 267 2 0 — 299 15 25
2
1 — Interpolation — 262 5 0 — 296 25 25
2
1 super
sample
— Interpolation — 708 32 0 — 914 34 27
2
1 super
sample
— Interpolation Write 841 32 0 — 1,297 32 25
9
1 — Interpolation Write 400 5 0 — 382 12 25
8
1 Half
Band
— Interpolation — 288 3 0 — 456 13 29
0
1 Half
Band
— Interpolation Write 331 4 0 — 315 9 29
0
1 — Single rate — 87 10 0 — 142 14 25
3
1 super
sample
— Single rate — 258 20 0 — 315 33 26
0
