4.5 VLAN
PSSnet SHL - Web- based Interface
Pilz GmbH & Co. KG, Felix- Wankel Str. 2, 73760 Ostfildern
Note: If you are using the GOOSE protocol in accordance with IEC61850-8-
1, you activate the “VLAN 0 transparent mode”. Thus the prioritizing informa-
tion remains in the data packet in accordance with IEEE802.1D/p even when
the device forwards the data packet.
This also applies to other protocols that use this prioritizing in accordance
with IEEE802.1D/p but that do not require any VLANs in accordance with
IEEE802.1Q.
Note: When using the “Transparent Mode” in this way, note the following:
In “Transparent mode”, the devices ignore the port VLAN ID set. Set the
VLAN membership of the ports of VLAN
1 to U (Untagged) or T (Tagged),
(see on page 91 „VLAN Static“) .
Parameter Meaning Value range Default setting
VLAN 0 Transpar-
ent Mode When this is activated, the VLAN ID “0”
remains in the packet, regardless of
the setting for the port VLAN ID in the
dialog
(see on page 93 „VLAN Port“) .
Activate the “VLAN 0 Transparent
Mode” to transmit packets with a prior-
ity TAG without VLAN membership,
that is with VLAN ID “0”.
on/off off
Table 19: VLAN settings
