CPS for Mac 10
Changing the Channel on RF Receivers
The clickers and receiver need to be set to the same channel to communicate.
1 Plug the receiver in to an available USB port and open CPS.
2 Click the Turning Technologies icon in the Menu Extras area and select Device Manager.
3 Select the receiver and then click the wrench icon . Alternatively, double-click the image of the receiver.
The Receiver Properties window opens.
4 Locate (RR)RF Receiver Options and click the arrows next to Base Channel to adjust the channel number or click once
on the channel number and use the keyboard to input a new channel number.
5 Click OK to save the channel number.
Changing the Channel on a CPS Pulse Clicker
The clickers need to be set to the same channel as the receiver when polling.
1 Press the Power button.
2 Simultaneously press both arrows and release.
3 Press the button.
Channel appears on the screen.
4 Enter the two-digit channel number.
NOTE
The channel number must be between 01 - 75.
5 Press the Enter button.
Clicker # appears on the screen.
6 Enter the number found on the front of the clicker.
7 Press the Enter button.
A summary appears on the screen, and the clicker turns off.
Changing the Channel on a CPS Spark Clicker
The clickers need to be set to the same channel as the receiver when polling.
1 Press the Power button.
2 Simultaneously press both arrows and release.
3 Press the button.
Channel appears on the screen.
4 Enter the first digit of the channel number by pressing the button to increase the number or the button to
decrease the number.
