First, select the correct battery type by fol-
lowing the instructions on page 18. Once you
have set the correct battery type, toggle up (▲) or down (▼) until
you see the “
LiPo STORAGE
” screen.
Toggle right (►) once and the amp rate val-
ue will begin flashing. Toggle up (▲) or down
(▼) to adjust the value to the desired rate. Follow the instructions
provided with your battery when setting the amp rate.
Toggle right (►) again and the cell count
value will begin flashing. Toggle up (▲) or
down (▼) to adjust the cell count. This will automatically change
the voltage value to the correct setting for the selected cell count.
The cell count should match the battery label exactly.
Toggle and hold the joysick to the right (►) for three seconds and
you will see “
BATTERY ChECK WAIT...
” followed by the “
CON-
fIRM
/
CANCEL
“ screen.
This screen displays the number of cells you set up as ”
R
” and the
number of cells detected by the processor as “
S
”. If both numbers
are identical, you may toggle right (►) once
to confirm and begin charging. If the cell
count does not match, toggle left (◄) once
to return to the previous screen and carefully check the number of
cells of the battery pack before proceeding.
Once charging has commenced, the charger will display the follow-
ing real-time information: battery type/cell count, charging current,
battery voltage, charging time and charged
capactiy.
lITHIuM - sToraGe Mode (cont.)
LiPo STORAGE
8.1A 22.2V(6S)
LiPo STORAGE
0.8A 22.2V(6S)
LiPo STORAGE
0.8A
11.1V(3S)
R:3SER S:3SER
CONfIRM(ENTER)
Li3s 1.2A 12.69V
STO 022:43 00682
