16
baTTerY connecTIons (cont.) oPeraTInG THe X1 Pro cHarGer
connecTInG THe baTTerY
before connecting a battery, it is absolutely essential to
check one last time that you have set the parameters correctly.
If the settings are incorrect, the battery may be damaged and
could even burst into fl ames or explode. To avoid short circuits
between the banana plugs, always connect the charge leads
to the charger fi rst, and only then to the battery. Reverse the
sequence when disconnecting the pack.
balance sockeT:
The balance wire attached to the battery must be connected to
the charger with the black wire aligned with the negative symbol
(▬). Take care to always maintain correct polarity! This im-
age shows the correct way to connect your battery to the X1
Pro while charging with the use of a balance adaptor. This is the
recommended method for charging and discharging.
