sYsTeM seT uP
When the X1 Pro is powered on for the first time, all system settings
will be set to default. Each parameter can be adjusted by the user,
allowing for greater control of the charge process for the specific
battery being charged.
When you power on the X1 Pro you will be at the “
PROGRAM SE-
LECT
” screen. Toggle up (▲) until you see “
SYSTEM SET->
”.
rest Time
During the charge>discharge or discharge>charge cycle, batteries
increase in temperature. The Rest Time program allows the user to
specify the time delay between cycles, allowing time for the battery
to cool.
Toggle right (►) once and you will see the
“
REST TIME
” screen. Toggle right (►) once
and the timer value will begin flashing. Toggle up (▲) or down (▼)
to adjust the timer value. The timer can be set at 0 to 60 minutes.
Toggle right (►) once to set the Rest Time.
safety Timer
When the charge process starts, the integrated safety timer starts
to run simultaneously. If an error occurs or the termination circuit
cannot detect whether the battery is fully charged, the X1 Pro is
programmed to prevent overcharging and will terminate the charg-
ing process.
safety Timer calculation
When charging NiCd or NiMH batteries, divide the capacity by the
current, then divide the result by 11.9. Set this number of minutes
as the setting for the safety timer setting. If the charger stops at this
time threshold, about 140% of the capacity will have been fed into
the battery.
Rest Time
ChG>DChG 8Min
sYsTeM seT uP (cont.)
