lITHIuM - fasT cHarGe Mode (cont.)
First, select the correct battery type by fol-
lowing the instructions on page 18. Once you
have set the correct battery type, toggle up (▲) or down (▼) until
you see the “
LiPo fAST ChG
” screen.
Toggle right (►) once and the amp rate val-
ue will begin flashing. Toggle up (▲) or down
( ▼) to adjust the value to the desired rate. Follow the instructions
provided with your battery when setting the amp rate.
Toggle right (►) again and the cell count
value will begin flashing. Toggle up (▲) or
down (▼) to adjust the cell count. This will automatically change
the voltage value to the correct setting for the selected cell count.
The cell count should match the battery label exactly.
Toggle and hold the joysick to the right (►) for three seconds and
you will see “
BATTERY ChECK WAIT...
” followed by the “
CON-
fIRM
/
CANCEL
“ screen.
This screen displays the number of cells
you set up as ”
R
” and the number of cells
detected by the processor as “
S
”. If both numbers are identical, you
may toggle right (►) once to confirm and begin charging. If the
cell count does not match, toggle left (◄) once to return to the
previous screen and carefully check the number of cells of the bat-
tery pack before proceeding.
Once charging has commenced, the charger
will display the following real-time informa-
tion: battery type/cell count, charging current, battery voltage,
charging time and charged capactiy.
LiPo fAST ChG
0.8A 22.2V(6S)
LiPo fAST ChG
0.8A
11.1V(3S)
R:3SER S:3SER
CONfIRM(ENTER)
Li3s 1.2A 12.69V
fAS 022:43 00682
LiPo fAST ChG
0.8A 22.2V(6S)
